| SPARE PARTS: One (1) Rivet on Retainer Kit. |
| Single Replacement Rivet on Retainer for Dzus PANEX system with Three (3) rivets. Rivet on Retainer is a DIRECT mechanical replacement for Yamaha Part Number 2TK-2177L-00-00.
|
| Kit Includes: | |
| 1 - 6mm Rivet on Panex Retainer | Coating: Zinc Plate with Chromate |
| 3 - 1/4" x 1/8" Pop Rivets | For attaching Rivet on Retainers Size: 1/4" x 1/8" 1 spare rivet - just in case |
| Dzus Clip Specs & Drawing | |
 |
Dzus Rivet On Retainer Specs / Info
Minimum flat space for clip: 35mmMinimum clearance behind bodywork:11mm Grip Range: 3.5mm to 5.4mm Maximum Grip with out washers
Minimum Grip using 2 washers |
| Yamaha Part and Application Info: | |
| Equivalent Yamaha P/N's: Main P/N: 2TK-2177L-00-00 |
2TK 2177L 00 00 2TK2177L0000 2TK21 77L0000 2TK217 7L0000 2T K2177 L0000 2TK2 177L 0000 2TK 217 7L0 000 2T K2 17 7L 00 00 |
| Yamaha Fitment List (Partial List): | 1999 YZFR7L YZFR7 COWLING 1 2007 PZ50FXW PHAZER FX FRAME 2007 PZ50GTW PHAZER GT FRAME 2007 PZ50MW PHAZER MOUNTAIN LITE FRAME 2007 PZ50VTW VENTURE LITE FRAME 2007 PZ50W PHAZER FRAME 2008 PZ50GTX PHAZER GT FRAME 2008 PZ50MTX PHAZER MOUNTAIN LITE FRAME 2008 PZ50RTX PHAZER RTX FRAME 2008 PZ50VTX VENTURE LITE FRAME 2008 PZ50X PHAZER FRAME |
